Features
- Lightweight, ergonomic, and easy to service
- Indexable angle head for added versatility
- Durable Clecomatic Clutch delivers best-in-class torque repeatability and long calibration cycle
- Heavy-duty Cleco motor is the industry standard for reliability
- Oil-less blades reduce oil mist in work area
| Model: | 24RAA23AM3 |
| Torque Range Min: | 9.0 ft/lbs |
| Torque Range Max: | 17.0 ft/lbs |
| Free Speed: | 600 1/min |
| Weight: | 3.20 lbs |
| Output Drive: | 3/8 Square Drive in|mm |
| Length: | 15.0 in |
| Side To Center: | 0.52 in |
| Angle Head Height: | 1.16 in |
| Air Consumption: | 23.9 SCFM |
| Air Inlet Size: | 3/8 in |
| Min Hose Id: | 1/2 in |
