Documentation
Description
Features
- Excellent combination of performance, comfort, and value
- Powerful twin hammer mechanism
- Variable speed trigger
- Light-weight and ergonomically balanced
- Ideal for general industrial production, maintenance, and overhaul
| Model: | CV-500R |
| Torque Range Min: | 50 ft/lbs |
| Torque Range Max: | 780 ft/lbs |
| Blows Per Minute: | 1200 |
| Free Speed: | 8500 1/min |
| Length: | 7.6 in |
| Weight: | 4.8 lbs |
| Air Inlet Size: | 1/4 in |
| Min Hose Id: | 3/8 in |
| Air Consumption: | 40.5 SCFM |
| Breakaway Torque: | 1100 ft/lbs |
| Drive Size: | 1/2" |
| Drive Type: | Retaining Ring |
