Description
Measurement Type: Metric
Bearing Rating: 10,000 rpm
Bearing Type: Dual Ball Bearings
Heavy Duty Thrust Bearing: Yes
Incremental Adjustment: 0.013 mm
Shaft Travel: 7.60 mm
Dust Seal: Integrated Dust Seal
Cutter Thread: M6x1
Shaft: Standard
Shaft Diameter: 6.35 mm
Cutter Capacity: 15 mm
Skirt: Slotted Internal Thread
Skirt Description: 25.4 mm OD 15 mm Cutter Capacity
Foot: Nylon
Solid Stop: Yes
