Documentation
Description
Measurement Type: Imperial
Bearing Rating: 10,000 rpm
Bearing Type: Dual Ball Bearings
Heavy Duty Thrust Bearing: Yes
Incremental Adjustment: 0.0005 in
Shaft Travel: 0.300 in
Dust Seal: Integrated Dust Seal
Cutter Thread: 1/4-28
Shaft: Standard
Shaft Diameter: 1/4 in
Cutter Capacity: 5/8 in
Skirt: Straight 0.875 in OD
Skirt Description: 0.875 in OD 5/8 in Cutter Capacity
Solid Stop: Yes
See also WES596-S-875 - Wescon Model 596 Microstop - 5/8 in Cutter Capacity - Straight Skirt
